Equipment
Laboratory equipment
The group operates laboratories for optical and structural characterization of nanostructures as well as some chemical equipment:
Micro-photoluminescence. Inverted optical microscope in a light-proof box with a motorized X-Y-Z stage. A spectrometer with a cooled CCD camera are attached for microphotoluminescence characterization with blue and green laser diode for excitation. AFM unit can be placed on top of the microscope for combined PL-AFM measurements. Cryostat can be placed for low temperature measurements and two APD detectors are used for photon counting and time-resolved studies down to single particle resolution.
![](/polopoly_fs/1.1241611.1679581021!/image/IS.jpg)
Integrating sphere. For quantum yield, haze, transparency, reflection and absorption measurements. The excitation source is a laser-driven white light source, where the excitation wavelength can be chosen by a spectrometer attached to it. The detection system consists of a cooled CCD with a spectrometer attached (300-1000 nm range). Another detection system is with an InGaAs detector (950-1700 nm).
![](/polopoly_fs/1.1217851.1672909155!/image/Sunbrick1.jpg)
Solar Simulator An LED-based large area (25x25 cm^2) solar simulator for EQE and PCE measurements.
![](/polopoly_fs/1.1241613.1679581075!/image/Schlenk%20line.jpg)
Schlenk line. Fume hood and a glove box for chemical processing and nanoparticle synthesis in inert atmosphere.
![](/polopoly_fs/1.1217852.1672909291!/image/Rotary%20evaporator_centrifuge.jpg)
Rotary evaporator and centrifuge Equipment for nanoparticle extraction from the solution
